P0.93 P1.25 P1.56 LED TV Display Screen Advertising Display Screen

Name: P093 P125 P156 LED TV Display Screen Advertising Display Screen
Brand: LongRunLED
Price: 800 USD

Brand Name : LongRunLED

Model Number : Indoor fixed display

Certification : CE

Place of Origin : Guangdong,China

MOQ : 2pcs

Price : 800USD/pc

Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram

Supply Ability : 200pcs/week

Delivery Time : 15~25days

Packaging Details : Plywood case/Fight case

Application : indoor led advertising display screen

Color : Full color RGB

Module size : 150x168.75mm

Cabinet size : 600x337.5x32mm

Cabinet material : Die casting aluminum

Pixel pitch : 0.93/1.25/1.56mm

Technology : COB

Refresh rate : 3840Hz

Brightness : 600-800cd

Contact Now

P0.93 P1.25 P1.56 LED TV Display Screen Advertising Display Screen

Indoor COB P1.56 2K 4K LED Display Screen

Product Description

Model	P1.25	P1.56
Pitch(mm)	1.25	1.56
Density(dot/sqm)	640,000	409,600
Pixel Configuration	1RGB	1RGB
Module Size(mm*mm)	150*168.75	150*168.75
Dot Rank(px*px)	120*135	96*108
Scaning Method	1/30	1/48
Grayscale(bit)	14	14
Refresh Rate(Hz)	3840	3840
Driving Method	Constant Current Drive
Horizontal Viewing Angle	>=170	>=170
Vertical Viewing Angle	>=170	>=170
Cabinet Weight(kg)	6
Cabinet Size(mmmmmm)	60078337.5
Cabinet Resolution(px*px)	480*270	384*216
Cabinet Material	Die-casting Aluminium
Color(M)	>16.7	>16.7
Output Voltage(V)	AC110-220V+/-10%
Repetition Frequency(Hz)	50-60
Proof Level	IP45
Usage Environment	Indoor
Working Temperature(°C)	-40°C - +60°C
Storage Humidity(RH)	40%-60%
Lifespan(H)	100,000

P0.93 P1.25 P1.56 LED TV Display Screen Advertising Display Screen

Our Advantage

P0.93 P1.25 P1.56 LED TV Display Screen Advertising Display Screen

Company Information

LED Module Production line:

Our Services

2018 LONGRUN hot sale P3 indoor led display module

Reply your inquiry in 12 hours.
Experienced staffs answer all your query in fluent English.
Customized design is available, OEM & ODM are welcomed.
Exclusive and unique solution can be provided to our customer by our well-trained and professional staffs.

FAQ

2018 LONGRUN hot sale P3 indoor led display module2018 LONGRUN hot sale P3 indoor led display module

Q: What is the brightness, viewing angle and wavelength of the LED?

A: Luminous Intensity is equal to the amount of luminous flux emitted into a very small solid angle at a defined angular orientation from the light source. The measurement for luminous intensity is the candela. Symbol is Iv.
Viewing Angle is the total cone angle in degrees encompassing the central, high luminous intensity portion of the LED beam from the on-axis peak to the off-axis point where the LED intensity is 50% of the on-axis intensity. This off-axis point is known as theta one-half ( 1/2). Two times 1/2 is the LEDs' full viewing angle; however, light is visible beyond the1/2 point.
Wavelength is the distance between two points of corresponding phase and is equal to waveform velocity divided by frequency. It defines what color human eyes could recognize

Q: What is dominant wavelength? Please specify the ranges of wavelength in red, green and blue color respectively.

A: Dominant wavelength is defined as the best range of wavelength showing the most natural color recognized by human eyes. Researches indicate that fixed colors with wavelength of 620-630nm (red), 520-530nm (green) and 460-470nm (blue), in fact mixed in a particular proportion, can get the pure white. That is, in display field, people use luminous materials with above wavelength to make "compounded" white more natural.In order to get a good balance white led display, we specify the led colors with wavelength within 4nm for each color

Q: Which chip vendors are you buying from?

A: It depends on the Customer's requirement. We can purchase from Japan, Korea, Europe, USA. We are using chips mainly from Taiwan

Q: What is the chip size you're using for outdoor display? How about indoor display?

A: For outdoor display, we're using 12mil chip for red, 14mil for both green and blue. Regarding indoor display, 9mil for red, 12mil for green and blue are currently adopted

Q: How much will the brightness of LED drop down after 1000hrs?

A: Based on the result of aging test, the brightness decay of green LED is around 5%-8%, while blue is around 10%-14% and red is around 5%-8%
